- With standard equipment
- With safety pack
Find more information in the General Comments section of the assessment
Find more information in the Rating Validity tab of the assessment
-
See More
![]()
87% -
See More
![]()
83% -
See More
![]()
69% -
See More
![]()
87%
- Good
- Adequate
- Marginal
- Weak
- Poor
-
![]()
Mobile Progressive Deformable Barrier![]()
-
![]()
Full Width Rigid Barrier
-
![]()
Side Mobile Barrier
![]()
Side Pole
-
![]()
Far-Side Excursion
Occupant Interaction![]()
Occupant Interaction
Rear Seat
Front Seat
| Rescue Sheet |
Available, ISO compliant
|
|||
| Advanced eCall | Available | |||
| Multi Collision Brake | Not available | |||
- Good
- Adequate
- Marginal
- Weak
- Poor
Passenger
outboard
center
![]()
Fitted to the vehicle as standard![]()
Not fitted to the test vehicle but available as option![]()
Not Available
-
i-Size CRS
-
ISOFIX CRS
-
Universal Belted CRS
![]()
Easy![]()
Difficult![]()
Safety critical![]()
Not allowed
Safety critical| Seat Position | ||||
|---|---|---|---|---|
| Front | 2nd row | |||
| Passenger | Left | center | Right | |
| Maxi Cosi 2way Pearl & 2wayFix (i-Size) | |
|
 |
|
| Maxi Cosi 2way Pearl & 2wayFix (i-Size) | |
|
|
|
| BeSafe iZi Kid X2 i-Size (i-Size) | |
|
|
|
| Britax Römer TriFix2 i-Size (i-Size) | |
|
|
|
| BeSafe iZi Flex FIX i-Size (i-Size) | |
|
|
|
| BeSafe iZi Combi X4 ISOfix (ISOFIX) | |
|
|
|
| Cybex Solution Z i-Fix (ISOFIX) | |
|
|
|
| Maxi Cosi Cabriofix (Belt) | |
|
 |
|
| Maxi Cosi Cabriofix & EasyFix (Belt) | |
|
|
|
| Britax Römer King II LS (Belt) | |
|
|
|
| Cybex Solution Z i-Fix (Belt) | |
|
|
|
![]()
Easy![]()
Difficult![]()
Safety critical![]()
Not allowed
The Rafale provided good or adequate protection to all critical body areas of the 6 and 10 year dummies, both in the frontal offset test and the side barrier impact. The front passenger airbag can be disabled to allow a rearward-facing child restraint to be used in that seating position. Clear information is provided to the driver regarding the status of the airbag and the system was rewarded. The user manual precludes the use of universal child restraints on the rear centre seat. Otherwise, all of the child restraints for which the Rafale is designed could be properly installed and accommodated in the car.
- Good
- Adequate
- Marginal
- Weak
- Poor
Head Impact 14.1 Pts
Pelvis Impact 2.7 Pts
Leg Impact 6.0 Pts
| System Name | Active Emergency Braking System | ||
| Type | Auto-Brake with Forward Collision Warning | ||
| Operational From | 8 km/h | ||
| PERFORMANCE | | |||
- Day time
- Night time
Day time
-
Vehicle reversing into standing pedestrian
-
Pedestrian crossing a road into which a car is turning
-
Adult crossing the road
-
Child running from behind parked vehicles
-
Adult along the roadside
Night time
-
Adult crossing the road
-
Adult along the roadside
-
Cyclist from nearside, obstructed view
-
Approaching a crossing cyclist
-
Cyclist along the roadside
The protection offered by the bonnet to the head of a struck pedestrian was predominantly good or adequate, with areas of weak and poor protection at the base of the windscreen and on the stiff windscreen pillars. The bumper provided good or adequate protection to pedestrians’ legs at all test positions but protection of the pelvis was mixed. The Rafale's autonomous emergency braking (AEB) system detects vulnerable road users like pedestrians and cyclists, as well as other vehicles. In tests of the system's response to such road-users, performance was rated as good, with collisions avoided or mitigated in most test scenarios.
- Good
- Adequate
- Marginal
- Weak
- Poor
| System Name | Speed Limiter |
| Speed Limit Information Function | Camera based, subsigns supported |
| Speed Control Function | System advised (accurate to 5km/h) |
| Applies To | Front and rear seats | ||
| Warning | Driver Seat | Front Passenger(s) | Rear Passenger(s) |
| Visual | |
|
|
| Audible | |
|
|
| Occupant Detection | |
|
|
|
|||
| System Name | Lane Keep Assist |
| Type | LKA and ELK |
| Operational From | 65 km/h |
| Performance | |
| Emergency Lane Keeping | |
| Lane Keep Assist | |
| Human Machine Interface | |
| System Name | Active Emergency Braking System | |||
| Type | Autonomous emergency braking and forward collision warning | |||
| Operational From | 7 km/h | |||
| Sensor Used | camera and radar | |||
- Autobrake function only
- Driver reacts to warning
Autobrake function only
-
Car turning across the path of an oncoming car
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a braking car
Driver reacts to warning
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a braking car
The Rafale's autonomous emergency braking (AEB) system performed well in tests of its reaction to other vehicles, with impacts avoided in most test cases. A seatbelt reminder system, including occupant detection, is standard for all seats and the car is also equipped with a driver monitoring system, which monitors steering inputs for patterns which are characteristic of a fatigued or inattentive driver. Lane assistance corrects the car's path if it is drifting out of lane and which also intervenes in some more critical situations. A camera based speed assistance system recognises local speed limits, allowing the speed limiter to be set appropriately.
- Specifications
- Safety Equipment
- Videos
- Rating Validity
Specifications
Tested Model Renault Austral 1,3 Tce, LHD
Body Type - 5 door MPV
Year Of Publication 2022
Kerb Weight 1502kg
VIN From Which Rating Applies - all Rafale HEV and PHEV
Class Large MPV
Safety Equipment
Note: Other equipment may be available on the vehicle but was not considered in the test year.
![]()
Fitted to the vehicle as standard![]()
Fitted to the vehicle as part of the safety pack![]()
Not fitted to the test vehicle but available as option or as part of the safety pack![]()
Not available![]()
Not applicable
Fitted to the vehicle as part of the safety packVideos
Rating Validity
Variants of Model Range
| Body Type | Engine | Drivetrain | Rating Applies | |
|---|---|---|---|---|
| LHD | RHD | |||
| 5 door MPV | 1.2 Tce E-Tech 200 Hybride * | 4 x 2 |  |
|
| 5 door MPV | 1.2 Tce E-Tech 230 Plug-In Hybride ** | 4 x 4 | |
|
* Tested variant and Renault Austral 1.3 Tce, LHD
** Additional tests performed
Find more information in the General Comments section of the assessment
Share
The passenger compartment of the Rafale remained stable in the frontal offset test. Dummy numbers showed good protection of the knees and femurs of both the driver and passenger. Analysis of the driver's side dashboard after the test revealed some areas which could be more injurious to occupants of different sizes and to those sitting in different positions. Protection of the driver’s chest was rated as marginal, based on dummy readings of compression. Analysis of the deceleration of the impact trolley during the test, and analysis of the deformable barrier after the test, revealed that the Austral would be a moderately benign impact partner in a frontal collision. In the full width rigid barrier test, dummy readings of chest compression revealed marginal protection of this body region for the rear passenger. All other critical body areas were rated as good or adequate, both for the driver and rear passenger. In the side barrier test, protection of all critical body regions was good. In the more severe side pole impact, chest protection was rated as marginal, based on dummy readings of rib compression. This is a poorer result than that of the Austral but does not affect the overall star rating. Limitation of occupant excursion - the extent to which the occupant is flung to the other side of the vehicle in a side impact - was rated as adequate. The Rafale has a centre airbag as a counter-measure against occupant to occupant injuries in side impacts. In Euro NCAP’s test, the airbag performed well, with good protection of the heads of the front seat occupants. Tests on the front seats and head restraints demonstrated good protection against whiplash injures in the event of a rear-end collision. A geometric assessment of the rear seats also indicated good whiplash protection. The Rafalehas an advanced eCall system to alert the emergency services in the event of a collision and a system that automatically to avoid secondary collisions, although the latter was not assessed by Euro NCAP.
