- With standard equipment
- With safety pack
Find more information in the General Comments section of the assessment
Find more information in the Rating Validity tab of the assessment
-
See More
![]()
86% -
See More
![]()
87% -
See More
![]()
66% -
See More
![]()
70%
- Good
- Adequate
- Marginal
- Weak
- Poor
-
![]()
Mobile Progressive Deformable Barrier![]()
-
![]()
Full Width Rigid Barrier
-
![]()
Side Mobile Barrier
![]()
Side Pole
-
![]()
Far-Side Excursion
Occupant Interaction![]()
Occupant Interaction
Rear Seat
Front Seat
| Rescue Sheet |
Available, ISO compliant
|
|||
| Advanced eCall | Available | |||
| Multi Collision Brake | Available | |||
- Good
- Adequate
- Marginal
- Weak
- Poor
Passenger
outboard
center
![]()
Fitted to the vehicle as standard![]()
Not fitted to the test vehicle but available as option![]()
Not Available
Not fitted to the test vehicle but available as option-
i-Size CRS
-
ISOFIX CRS
-
Universal Belted CRS
![]()
Easy![]()
Difficult![]()
Safety critical![]()
Not allowed
Difficult
Safety critical| Seat Position | ||||
|---|---|---|---|---|
| Front | 2nd row | |||
| Passenger | Left | center | Right | |
| Maxi Cosi 2way Pearl & 2wayFix (i-Size) |  |
|
|
|
| Maxi Cosi 2way Pearl & 2wayFix (i-Size) | |
|
|
|
| BeSafe iZi Kid X2 i-Size (i-Size) | |
|
|
|
| Britax Römer TriFix2 i-Size (i-Size) | |
|
|
|
| BeSafe iZi Flex FIX i-Size (i-Size) | |
|
|
|
| BeSafe iZi Combi X4 ISOfix (ISOFIX) | |
|
|
|
| Cybex Solution Z i-Fix (ISOFIX) | |
|
|
|
| Maxi Cosi Cabriofix (Belt) | |
|
|
|
| Maxi Cosi Cabriofix & EasyFix (Belt) | |
|
|
|
| Britax Römer King II LS (Belt) | |
|
|
|
| Cybex Solution Z i-Fix (Belt) | |
|
|
|
![]()
Easy![]()
Difficult![]()
Safety critical![]()
Not allowed
In the both the frontal offset test and the side barrier impact, protection of all critical body areas was good or adequate for both child dummies. The front passenger airbag can be disabled to allow a rearward-facing child restraint to be used in that seating position. Clear information is provided to the driver regarding the status of the airbag and the system was rewarded. All of the child restraint types for which the TUCSON is designed could be properly installed and accommodated in the car.
- Good
- Adequate
- Marginal
- Weak
- Poor
Head Impact 16.2 Pts
Pelvis Impact 1.6 Pts
Leg Impact 6.0 Pts
| System Name | Forward Collision-Avoidance Assist | ||
| Type | Auto-Brake with Forward Collision Warning | ||
| Operational From | 5 km/h | ||
| PERFORMANCE | | |||
- Day time
- Night time
Day time
-
Vehicle reversing into standing pedestrian
-
Pedestrian crossing a road into which a car is turning
-
Adult crossing the road
-
Child running from behind parked vehicles
-
Adult along the roadside
Night time
-
Adult crossing the road
-
Adult along the roadside
-
Cyclist from nearside, obstructed view
-
Approaching a crossing cyclist
-
Cyclist along the roadside
Good or adequate protection was provided to the head of a struck pedestrian over most of the bonnet surface, with some areas of poor protection on the stiff windscreen pillars. The bumper provided good protection to pedestrians’ legs at all test locations. However, protection of the pelvis was predominantly poor. The autonomous emergency braking system of the TUCSON detects vulnerable road users, as well as other vehicles. The system’s response to pedestrians was adequate and to cyclists was good.
- Good
- Adequate
- Marginal
- Weak
- Poor
| System Name | Manual Speed Limit Assist (MSLA) / Intelligent Speed Limit Assist (ISLA) |
| Speed Limit Information Function | Camera based, subsigns supported |
| Speed Control Function | System advised (accurate to 5km/h) |
| Applies To | Front and rear seats, including third row | ||
| Warning | Driver Seat | Front Passenger(s) | Rear Passenger(s) |
| Visual | |
|
|
| Audible | |
|
|
| Occupant Detection | |
|
|
|
|||
| System Name | Driver Attention Alert |
| Type | Steering inputs |
| Operational From | 30 km/h |
| System Name | LKA-L / LKA-R |
| Type | LKA and ELK |
| Operational From | 60 km/h |
| Performance | |
| Emergency Lane Keeping | |
| Lane Keep Assist | |
| Human Machine Interface | |
| System Name | Forward Collision-Avoidance Assist | |||
| Type | Autonomous emergency braking and forward collision warning | |||
| Operational From | 5 km/h | |||
| Sensor Used | camera | |||
- Autobrake function only
- Driver reacts to warning
Autobrake function only
-
Car turning across the path of an oncoming car
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a braking car
Driver reacts to warning
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a stationary car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a slower moving car
-
Approaching a braking car
A seatbelt reminder is standard for the front and rear seats. A driver monitoring system monitors steering inputs for signs of fatigued driving. The autonomous emergency braking system showed only marginal performance in tests of its reaction to other vehicles. A more advanced AEB system is available as an option which protects against other types of accidents, but that system is not included in this assessment. Speed assistance is provided by a system which informs the driver of the local limit, and which can automatically set the speed limiter to the appropriate speed. A lane support system gently corrects the course of a car which is drifting out of lane and also intervenes in more critical situations.
- Specifications
- Safety Equipment
- Videos
- Rating Validity
Specifications
Tested Model Hyundai TUCSON 1.6 T-GDI HEV GLS, LHD
Body Type - 5 door SUV
Year Of Publication 2021
Kerb Weight 1633kg
VIN From Which Rating Applies - all TUCSONs
Class Small SUV
Safety Equipment
Note: Other equipment may be available on the vehicle but was not considered in the test year.
![]()
Fitted to the vehicle as standard![]()
Fitted to the vehicle as part of the safety pack![]()
Not fitted to the test vehicle but available as option or as part of the safety pack![]()
Not available![]()
Not applicable
Fitted to the vehicle as part of the safety packVideos
Rating Validity
Variants of Model Range
| Body Type | Engine | Drivetrain | Rating Applies | |
|---|---|---|---|---|
| LHD | RHD | |||
| 5 door SUV | 1.6 T-GDI |
4 x 2 4 x 4 |
 |
|
| 5 door SUV | 1.6 T-GDI 48V MHEV |
4 x 2 4 x 4 |
|
|
| 5 door SUV | 1.6 T-GDI HEV |
4 x 2 4 x 4* |
|
|
| 5 door SUV | 1.6 T-GDI PHEV |
4 x 4 |
|
|
| 5 door SUV | 1.6 CRDi |
4 x 2 |
|
|
| 5 door SUV | 1.6 CRDi 48V MHEV |
4 x 2 4 x 4 |
|
|
* Tested variant
Find more information in the General Comments section of the assessment
Share
The passenger compartment of the TUCSON remained stable in the frontal offset test. Dummy numbers showed good protection of the knees and femurs of both the driver and passenger. Hyundai showed that a similar level of protection would be provided to the legs of occupants of different sizes and to those sitting in different positions. Protection of the driver’s chest was marginal. Analysis of the deceleration of the impact trolley during the test, and analysis of the deformable barrier after the test, revealed that the TUCSON would be a moderately benign impact partner in a frontal collision. In the full-width rigid barrier test, good or adequate protection was provided to most critical body areas. However, driver chest protection was rated as marginal, based on dummy readings of compression. In the side barrier test, protection of all critical body areas was good or adequate. In the more severe side pole impact, protection of all critical body areas was good and the car scored maximum points for this part of the assessment. The TUCSON has a centre airbag to mitigate occupant to occupant injuries in the event of a lateral collision. In Euro NCAP’s test, the airbag worked well, with good protection of the dummies’ heads. Limitation of the extent to which a body is thrown to the other side of the car in a side impact was rated as adequate. Tests on the front seats and head restraints demonstrated good protection against whiplash injuries in the event of a rear-end collision. A geometric analysis of the rear seats also indicated marginal whiplash protection. The TUCSON has, as standard, an advanced emergency call system which alerts the emergency services in the event of a crash. The car also applies the brakes after a collision to prevent secondary impacts.
