- With standard equipment
- With safety pack
Find more information in the General Comments section of the assessment
Find more information in the Rating Validity tab of the assessment
- See More
- See More
- See More
- See More
- Good
- Adequate
- Marginal
- Weak
- Poor
-
Approaching a stationary car: Left Offset
-
Approaching a stationary car: No Offset
-
Approaching a stationary car: Right Offset
- Good
- Adequate
- Marginal
- Weak
- Poor
Passenger
outboard
center
- Fitted to the vehicle as standard
- Not fitted to the test vehicle but available as option
- Not Available
-
i-Size CRS
-
ISOFIX CRS
-
Universal Belted CRS
- Easy
- Difficult
- Safety critical
- Not allowed
Seat Position | ||||
---|---|---|---|---|
Front | 2nd row | |||
Passenger | Left | center | Right | |
Maxi Cosi 2way Pearl & 2wayFix (rearward) (iSize) | ||||
Maxi Cosi 2way Pearl & 2wayFix (forward) (iSize) | ||||
BeSafe iZi Kid X2 i-Size (iSize) | ||||
Maxi Cosi Cabriofix & FamilyFix (ISOFIX) | ||||
BeSafe iZi Kid X4 ISOfix (ISOFIX) | ||||
Britax Römer Duo Plus (ISOFIX) | ||||
Britax Römer KidFix XP (ISOFIX) | ||||
Maxi Cosi Cabriofix (Belt) | ||||
Maxi Cosi Cabriofix & EasyBase2 (Belt) | ||||
Britax Römer King II LS (Belt) | ||||
Britax Römer KidFix XP (Belt) |
- Easy
- Difficult
- Safety critical
- Not allowed
Protection of both the 6 year and 10 year dummies was good in both the frontal offset and side barrier tests. The front passenger airbag can be disabled to allow a rearward-facing child restraint to be used in that seating position. Clear information is provided to the driver regarding the status of the airbag and the system was rewarded. All of the restraint types for which the XC40 is designed could be properly installed and accommodated in the vehicle.
- Good
- Adequate
- Marginal
- Weak
- Poor
Head Impact 17.1 Pts
Pelvis Impact 3.1 Pts
Leg Impact 6.0 Pts
System Name | Volvo City Safety | ||
Type | Auto-Brake with Forward Collision Warning | ||
Operational From | 4 km/h | ||
PERFORMANCE | |
-
Approaching a crossing cyclist
-
Cyclist along the roadside
The bonnet provided good or adequate protection to the head of a struck pedestrian over most of its surface, with poor results only on the stiff windscreen pillars. The bumper scored maximum points for its protection of pedestrians' legs, with good results at all test locations. Protection of the pelvis was more mixed, with areas of good and poor protection. The autonomous emergency braking system performed well in all daylight tests against a pedestrian target. In darkness, the system performed well in detecting a pedestrian walking in the same direction but was weak in tests with a target crossing the vehicle's path. The same system performed adequately in daylight tests with a cyclist target.
- Good
- Adequate
- Marginal
- Weak
- Poor
System Name | Road Sign Information & Speed Limiter |
Speed Limit Information Function | Camera based |
Speed Control Function | System advised (accurate to 5km/h) |
Applies To | All seats | ||
Warning | Driver Seat | Front Passenger(s) | Rear Passenger(s) |
Visual | |||
Audible | |||
Occupant Detection | |||
|
System Name | Lane Departure Warning with Lane Keeping Aid |
Type | ELK + LKA (including LDW) |
Operational From | 65 km/h |
Performance | |
Emergency Lane Keeping | |
Lane Keep Assist | |
Human Machine Interface |
System Name | City Safety | |||
Type | Autonomous Emergency Braking and Forward Collision Warning | |||
Operational From | 4 km/h | |||
Additional Information | Supplementary warning |
The XC40 has a seatbelt reminder system for the front and rear seats. A standard-fit speed assistance system identifies the local speed limit and allows the driver to set the speed accordingly. The system performed adequately in Euro NCAP's tests. The autonomous emergency braking system worked well in all test simulations of highway scenarios, losing only a fraction of a point. The standard-fit lane assistance system comprises Lane Keep Assistance, which warns the driver when the car is drifting out of lane and gently applies the steering to correct the path, and Emergency Lane Keeping, which intervenes much more aggressively in emergency situations, to keep the car on the road or from hitting another vehicle.
- Specifications
- Safety Equipment
- Videos
- Rating Validity
Specifications
Tested Model Volvo XC40 D4 AWD Momentum
Body Type - 5 door SUV
Year Of Publication 2018
Kerb Weight 1680kg
VIN From Which Rating Applies - all XC40s, including XC40 Recharge (from 2021)
Class Small SUV
Safety Equipment
Note: Other equipment may be available on the vehicle but was not considered in the test year.
- Fitted to the vehicle as standard
- Fitted to the vehicle as part of the safety pack
- Not fitted to the test vehicle but available as option or as part of the safety pack
- Not available
- Not applicable
Videos
Rating Validity
Variants of Model Range
Body Type | Engine | Model Name/Code | Drivetrain | Rating Applies | |
---|---|---|---|---|---|
LHD | RHD | ||||
5 door SUV | 2.0 4-cyl diesel | XC40 D3 | 4 x 2 | ||
5 door SUV | 2.0 4-cyl diesel | XC40 D3 | 4 x 4 | ||
5 door SUV | 2.0 4-cyl diesel | XC40 D4* | 4 x 4 | ||
5 door SUV | 1.5 3-cyl petrol | XC40 T3 | 4 x 2 | ||
5 door SUV | 2.0 4-cyl petrol | XC40 T4 | 4 x 2 | ||
5 door SUV | 2.0 4-cyl petrol | XC40 T4 | 4 x 4 | ||
5 door SUV | 2.0 4-cyl petrol | XC40 T5 | 4 x 4 | ||
5 door SUV | Battery electric | XC40 Recharge# | 4 x 4 |
* Tested variant
# additional tests performed 2021
Find more information in the General Comments section of the assessment
Share
The passenger compartment of the XC40 remained stable in the frontal offset test. Dummy readings showed good protection of all critical body areas apart from the lower leg of the passenger, protection of which was adequate. Volvo showed that good protection would be provided to the knees and femurs of occupants of different sizes and to those sitting in different positions. In the full-width rigid barrier test, protection of the chest of the rear passenger dummy was rated as marginal, based on dummy readings of chest compression. The protection of all other critical body regions was rated as good for both dummies. In the side barrier and the more severe side pole tests, protection of all critical body areas was good and the XC40 scored maximum points in these tests. Tests on the front seats and head restraints demonstrated good protection of the neck against whiplash injuries in the event of a rear-end collision. A geometric assessment of the rear seats also indicated good whiplash protection. Volvo City Safety is standard equipment on the XC40. This autonomous emergency braking system performed well, avoiding collisions in all test scenarios of typical city driving.
